型號

回轉
直徑
D

公稱轉矩
Tn /N.m

疲勞轉矩
Tf
kN.m

軸線折角
β

伸縮量
Ls

尺寸

轉動貫量I
kg·m2

質量G kg

Lmin

D1
(js11)

D2
(H7)

D3

Lm

n-d

k

t

b
(h9)

g

Lmin

增長
100mm

Lmin

增長
100mm

SWC180CH1

180

12.5

6.3

≤25

200

925

155

105

114

110

8-17

17

5

-

-

0.181

0.0070

74

2.8

SWC180CH1

700

1425

0.216

104

SWC225CH1

225

40

20

≤15

220

1020

196

135

152

120

8-17

20

5

32

9

0.561

0.0234

132

4.9

SWC225CH2

700

1500

0.674

182

SWC250CH1

250

63

31.5

≤15

300

1215

218

150

168

140

8-19

25

6

40

12.5

1.016

0.0277

190

5.3

SWC250CH2

700

1615

1.127

235

SWC285CH1

285

90

45

≤15

400

1475

245

170

194

160

8-21

27

7

40

15

2.156

0.0510

300

6.3

SWC285CH2

800

1875

2.360

358

SWC315CH1

315

125

63

≤15

400

1600

280

185

219

180

10-23

32

8

40

15

3.812

0.0795

434

8.0

SWC315CH2

800

2000

4.150

514

SWC350CH1

350

180

90

≤15

400

1715

310

210

267

194

10-23

35

8

50

16

7.663

0.2219

672

15.0

SWC350CH2

800

2115

8.551

823

SWC390CH1

390

250

125

≤15

400

1845

345

235

267

215

10-25

40

8

70

18

12.730

0.2219

817

15.0

SWC390CH2

800

2245

13.617

964

SWC440CH1

440

355

180

≤15

400

2110

390

255

325

260

16-28

42

10

80

20

22.540

0.4744

1312

21.7

SWC440CH2

800

2510

24.430

1537

SWC490CH1

490

500

250

≤15

400

2220

435

275

325

270

16－31

47

12

90

22.5

33.970

0.4744

1554

21.7

SWC490CH2

800

2620

35.870

1779

SWC550CH1

550

710

355

≤15

500

2585

492

320

426

305

16-31

50

12

100

22.5

72.790

1.3570

2585

34

SWC550CH2

1000

3085

79.570

3045
